IFM Pressure Transmitter: 0 psi to 1,000 psi, 4 to 20mA DC, 4-Pin M12 Connector - Pressure Transmitters with 4-Pin M12 Connector
IFMPressure Transmitters with 4-Pin M12 Connector

IFM Pressure Transmitter: 0 psi to 1,000 psi, 4 to 20mA DC, 4-Pin M12 Connector

The IFM PX3222 is a pressure transmitter from the PX Series, featuring a 0 psi to 1,000 psi range with a 4 to 20mA DC output and a 4-Pin M12 Connector. It offers an accuracy of ±0.75%, an overpressure rating of 4,350…

SKU 3G-OTH-176693

Brand
IFM
Item
Pressure Transmitter: 0 psi to 1,000 psi, 4 to 20mA DC, 4-Pin M12 Connector
Category
Pressure Transmitters with 4-Pin M12 Connector
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

IFM
Manufacturer Part Number
PX3222
Series
PX
DC
4 to 20mA
Output
4 to 20mA DC
Accuracy
±0.75%
Male NPT
1/4 in
IP Rating
IP68
Overpressure
4,350 psi
M12 Connector
4-Pin
Burst Pressure
9,400 psi
Housing Material
Stainless Steel
Process Connection Type
NPT
Process Connection Gender
Male
Calibration Certificate Included
No NIST-Traceable Calibration Certificate Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

IFM Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The IFM PX3222 is a pressure transmitter from the PX Series, featuring a 0 psi to 1,000 psi range with a 4 to 20mA DC output and a 4-Pin M12 Connector. It offers an accuracy of ±0.75%, an overpressure rating of 4,350 psi, and a burst pressure of 9,400 psi. The stainless steel housing has an IP68 rating, and the process connection is a 1/4 in Male NPT. No NIST-traceable calibration certificate is included.

Frequently Asked Questions

What is the IFM PX3222 pressure transmitter used for?

The IFM PX3222 pressure transmitter measures pressure from 0 psi to 1,000 psi in industrial hydraulic and pneumatic systems. It outputs a 4 to 20mA DC signal for monitoring and control applications. Its stainless steel housing and IP68 rating suit harsh environments.

What are the specifications of the IFM PX3222 pressure transmitter?

The IFM PX3222 has a 0 psi to 1,000 psi range, ±0.75% accuracy, 4 to 20mA DC output, and a 4-Pin M12 Connector. Overpressure rating is 4,350 psi, burst pressure is 9,400 psi. Housing is stainless steel with IP68 rating. Process connection is 1/4 in Male NPT.

Where to buy the IFM PX3222 pressure transmitter worldwide?

You can source the IFM PX3222 pressure transmitter through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to install the IFM PX3222 pressure transmitter?

Install the IFM PX3222 by threading the 1/4 in Male NPT connection into a compatible port using appropriate sealant. Connect the 4-Pin M12 connector to a matching cable. Ensure the system is depressurized before installation. Follow standard torque guidelines for NPT fittings.
