IFM Pressure Transmitter: 0 psi to 500 psi, 4 to 20mA DC, 4-Pin M12 Connector
The IFM PX3223 is a pressure transmitter with a 4-pin M12 connector, offering a 0 psi to 500 psi range and a 4 to 20mA DC output. It features an accuracy of ±0.75%, an overpressure rating of 2,175 psi, and a burst…
SKU 3G-OTH-176690
Need installation or engineering help?
Ask a question
Product Description
The IFM PX3223 is a pressure transmitter with a 4-pin M12 connector, offering a 0 psi to 500 psi range and a 4 to 20mA DC output. It features an accuracy of ±0.75%, an overpressure rating of 2,175 psi, and a burst pressure of 5,075 psi. The stainless steel housing has an IP65 rating and a 1/4 in male NPT process connection.
Frequently Asked Questions
What is the IFM PX3223 pressure transmitter used for?
The IFM PX3223 pressure transmitter is used for monitoring and controlling pressure in industrial hydraulic, pneumatic, and process systems. It converts 0 psi to 500 psi into a 4 to 20mA DC signal for PLCs or controllers. Common applications include pump protection, tank level measurement, and filter monitoring in manufacturing and automation.
What are the specifications of the IFM PX3223 pressure transmitter?
The IFM PX3223 has a 0 psi to 500 psi range with 4 to 20mA DC output, accuracy ±0.75%, overpressure 2,175 psi, and burst pressure 5,075 psi. It features a stainless steel housing, IP65 rating, 1/4 in male NPT connection, and a 4-pin M12 connector. No NIST-traceable calibration certificate is included.
Where to buy the IFM PX3223 pressure transmitter worldwide?
You can source the IFM PX3223 pressure transmitter worldwide through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time; we provide competitive pricing and reliable sourcing for this IFM model.
How to install the IFM PX3223 pressure transmitter?
Install the IFM PX3223 by threading the 1/4 in male NPT connection into a compatible port using PTFE tape on threads. Torque to manufacturer specs (typically 15–20 ft-lb). Connect the 4-pin M12 connector to a mating cable, ensuring proper pinout for 4 to 20mA DC loop power. Avoid over-tightening to prevent damage.
