SMC Pressure Relief Valve: 1 in NPT, 1 in NPT Outlet Size, 125 psi Max Op Pressure - SMC Compressed Air Line Pressure-Relief Lockout Valves for FRLs
SMCSMC Compressed Air Line Pressure-Relief Lockout Valves for FRLs

SMC Pressure Relief Valve: 1 in NPT, 1 in NPT Outlet Size, 125 psi Max Op Pressure

The SMC VHS50-N10-BS-Z-D is a compressed air line pressure-relief lockout valve for FRLs, featuring a 1 in NPT inlet and outlet size. It has a maximum operating pressure of 125 psi and a maximum operating temperature…

SKU 3G-OTH-138383

Brand
SMC
Item
Pressure Relief Valve: 1 in NPT, 1 in NPT Outlet Size, 125 psi Max Op Pressure
Category
SMC Compressed Air Line Pressure-Relief Lockout Valves for FRLs
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SMC
Manufacturer Part Number
VHS50-N10-BS-Z-D
Max Op Temp
60°C
Max Op Pressure
125 psi
NPT Outlet Size
1 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SMC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SMC VHS50-N10-BS-Z-D is a compressed air line pressure-relief lockout valve for FRLs, featuring a 1 in NPT inlet and outlet size. It has a maximum operating pressure of 125 psi and a maximum operating temperature of 60°C, with a resin body construction.
