SMC Air Line Valve: 1 in NPT, 1 in NPT Outlet Size, 125 psi Max Op Pressure - SMC Compressed Air Line Pressure-Relief Lockout Valves for FRLs
SMCSMC Compressed Air Line Pressure-Relief Lockout Valves for FRLs

SMC Air Line Valve: 1 in NPT, 1 in NPT Outlet Size, 125 psi Max Op Pressure

The SMC Air Line Valve (SKU 890JX7, MPN VHS50-N10-Z-D) is a compressed air line pressure-relief lockout valve for FRLs, constructed of resin. It features a 1 in NPT inlet and outlet size, with a maximum operating…

SKU 3G-OTH-138384

Brand
SMC
Item
Air Line Valve: 1 in NPT, 1 in NPT Outlet Size, 125 psi Max Op Pressure
Category
SMC Compressed Air Line Pressure-Relief Lockout Valves for FRLs
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SMC
Manufacturer Part Number
VHS50-N10-Z-D
Type
Resin
Max Op Temp
60°C
Max Op Pressure
125 psi
NPT Outlet Size
1 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SMC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SMC Air Line Valve (SKU 890JX7, MPN VHS50-N10-Z-D) is a compressed air line pressure-relief lockout valve for FRLs, constructed of resin. It features a 1 in NPT inlet and outlet size, with a maximum operating pressure of 125 psi and a maximum operating temperature of 60°C.

Frequently Asked Questions

What is the SMC Air Line Valve VHS50-N10-Z-D used for?

The SMC Air Line Valve VHS50-N10-Z-D is a compressed air line pressure-relief lockout valve designed for FRLs. It isolates and relieves downstream pressure during maintenance, ensuring safe lockout/tagout procedures in pneumatic systems across industrial manufacturing and automation plants.

What are the specifications of the SMC VHS50-N10-Z-D valve?

The SMC VHS50-N10-Z-D valve has a resin body, 1 in NPT inlet and outlet sizes, maximum operating pressure of 125 psi, and maximum operating temperature of 60°C. It is a pressure-relief lockout valve for compressed air FRLs, manufactured by SMC.

Where to buy the SMC VHS50-N10-Z-D valve worldwide?

You can source the SMC VHS50-N10-Z-D valve through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations, ensuring the valve reaches your facility reliably.

How to install the SMC VHS50-N10-Z-D lockout valve?

To install the SMC VHS50-N10-Z-D, first depressurize the air line. Connect the 1 in NPT inlet to the upstream FRL outlet and the 1 in NPT outlet to downstream equipment. Tighten fittings securely, then test for leaks at 125 psi maximum. Follow SMC's generic lockout valve installation guidelines.
