SMC Air Line Valve: 1/2 in NPT, 1/2 in NPT Outlet Size, 125 psi Max Op Pressure - SMC Compressed Air Line Pressure-Relief Lockout Valves for FRLs
SMCSMC Compressed Air Line Pressure-Relief Lockout Valves for FRLs

SMC Air Line Valve: 1/2 in NPT, 1/2 in NPT Outlet Size, 125 psi Max Op Pressure

The SMC Air Line Valve (SKU 890JX2, MPN VHS40-N04-MZ-D) is a compressed air line pressure-relief lockout valve for FRLs, constructed with a metal body. It features a 1/2 in NPT inlet and outlet size, with a maximum…

SKU 3G-OTH-138386

Brand
SMC
Item
Air Line Valve: 1/2 in NPT, 1/2 in NPT Outlet Size, 125 psi Max Op Pressure
Category
SMC Compressed Air Line Pressure-Relief Lockout Valves for FRLs
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SMC
Manufacturer Part Number
VHS40-N04-MZ-D
Max Op Temp
60°C
Max Op Pressure
125 psi
NPT Outlet Size
1/2 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SMC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SMC Air Line Valve (SKU 890JX2, MPN VHS40-N04-MZ-D) is a compressed air line pressure-relief lockout valve for FRLs, constructed with a metal body. It features a 1/2 in NPT inlet and outlet size, with a maximum operating pressure of 125 psi and a maximum operating temperature of 60°C.

Frequently Asked Questions

What is the SMC VHS40-N04-MZ-D air line valve used for?

The SMC VHS40-N04-MZ-D is a compressed air line pressure-relief lockout valve designed for FRL units. It isolates pneumatic systems during maintenance by locking out air flow and relieving downstream pressure, ensuring worker safety in industrial plants, manufacturing lines, and automated machinery.

What are the specifications of the SMC VHS40-N04-MZ-D?

The SMC VHS40-N04-MZ-D has a metal body, 1/2 in NPT inlet and outlet, maximum operating pressure of 125 psi, and maximum operating temperature of 60°C. It is a pressure-relief lockout valve for compressed air FRLs, with MPN VHS40-N04-MZ-D.

Where to buy the SMC VHS40-N04-MZ-D worldwide?

3G Electric supplies the SMC VHS40-N04-MZ-D worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your facility. Contact us for availability and lead time on this SMC lockout valve.

How to install the SMC VHS40-N04-MZ-D lockout valve?

Install the SMC VHS40-N04-MZ-D by connecting the 1/2 in NPT inlet to the air supply line and the outlet to the FRL unit. Ensure the system is depressurized before installation. Use thread sealant on NPT fittings and verify the valve operates freely to lock out and relieve pressure.
