SMC Air Line Valve: 1 in NPT, 1 in NPT Outlet Size, 125 psi Max Op Pressure - SMC Compressed Air Line Pressure-Relief Lockout Valves for FRLs
SMCSMC Compressed Air Line Pressure-Relief Lockout Valves for FRLs

SMC Air Line Valve: 1 in NPT, 1 in NPT Outlet Size, 125 psi Max Op Pressure

The SMC Air Line Valve (SKU 890JX6, MPN VHS50-N10-MZ-D) is a compressed air line pressure-relief lockout valve for FRLs, constructed from metal. It features a 1 in NPT inlet and outlet size, with a maximum operating…

SKU 3G-OTH-138385

Brand
SMC
Item
Air Line Valve: 1 in NPT, 1 in NPT Outlet Size, 125 psi Max Op Pressure
Category
SMC Compressed Air Line Pressure-Relief Lockout Valves for FRLs
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SMC
Manufacturer Part Number
VHS50-N10-MZ-D
Type
Metal
Max Op Temp
60°C
Max Op Pressure
125 psi
NPT Outlet Size
1 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SMC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SMC Air Line Valve (SKU 890JX6, MPN VHS50-N10-MZ-D) is a compressed air line pressure-relief lockout valve for FRLs, constructed from metal. It features a 1 in NPT inlet and outlet size, with a maximum operating pressure of 125 psi and a maximum operating temperature of 60°C.

Frequently Asked Questions

What is the SMC VHS50-N10-MZ-D air line valve used for?

The SMC VHS50-N10-MZ-D is a compressed air line pressure-relief lockout valve designed for FRL units. It isolates and vents downstream air during maintenance, ensuring safe lockout/tagout procedures in industrial pneumatic systems.

What are the specifications of the SMC VHS50-N10-MZ-D valve?

This SMC valve has a 1 in NPT inlet and outlet size, a maximum operating pressure of 125 psi, and a maximum operating temperature of 60°C. It is constructed from metal and carries the MPN VHS50-N10-MZ-D.

Where to buy the SMC VHS50-N10-MZ-D valve worldwide?

3G Electric supplies the SMC VHS50-N10-MZ-D valve worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time.

How to install the SMC VHS50-N10-MZ-D lockout valve?

Install the SMC VHS50-N10-MZ-D valve inline with your FRL system using standard NPT fittings. Ensure the valve is oriented for proper flow direction, and test for leaks after installation. Follow SMC's generic lockout/tagout best practices for safe operation.
