SMC Air Line Valve: 1/4 in NPT, 1/4 in NPT Outlet Size, 125 psi Max Op Pressure - SMC Compressed Air Line Pressure-Relief Lockout Valves for FRLs
SMCSMC Compressed Air Line Pressure-Relief Lockout Valves for FRLs

SMC Air Line Valve: 1/4 in NPT, 1/4 in NPT Outlet Size, 125 psi Max Op Pressure

The SMC VHS20-N02-Z-D is a compressed air line pressure-relief lockout valve for FRLs, featuring a 1/4 in NPT inlet and outlet. It is constructed with a resin body and has a maximum operating pressure of 125 psi and…

SKU 3G-OTH-138376

Brand
SMC
Item
Air Line Valve: 1/4 in NPT, 1/4 in NPT Outlet Size, 125 psi Max Op Pressure
Category
SMC Compressed Air Line Pressure-Relief Lockout Valves for FRLs
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SMC
Manufacturer Part Number
VHS20-N02-Z-D
Max Op Temp
60°C
Max Op Pressure
125 psi
NPT Outlet Size
1/4 in
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SMC Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SMC VHS20-N02-Z-D is a compressed air line pressure-relief lockout valve for FRLs, featuring a 1/4 in NPT inlet and outlet. It is constructed with a resin body and has a maximum operating pressure of 125 psi and a maximum operating temperature of 60°C.

Frequently Asked Questions

What is the SMC VHS20-N02-Z-D compressed air line valve used for?

The SMC VHS20-N02-Z-D is a pressure-relief lockout valve for FRLs (filter-regulator-lubricator) in compressed air systems. It isolates and depressurizes downstream air lines for safe maintenance, commonly used in industrial automation, pneumatic controls, and manufacturing plants.

What are the specifications of the SMC VHS20-N02-Z-D?

The SMC VHS20-N02-Z-D has 1/4 in NPT inlet and outlet sizes, a maximum operating pressure of 125 psi, and a maximum operating temperature of 60°C. Its body is made of resin. The manufacturer part number is VHS20-N02-Z-D.

Where to buy the SMC VHS20-N02-Z-D worldwide?

3G Electric supplies the SMC VHS20-N02-Z-D worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time on this pneumatic lockout valve.

How to install the SMC VHS20-N02-Z-D lockout valve?

Install the SMC VHS20-N02-Z-D by connecting the 1/4 in NPT inlet to the upstream air line and the outlet to the FRL unit. Ensure the system is depressurized before installation. Use thread sealant on NPT fittings and verify the valve operates freely for lockout safety.
