SQUARE D NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 4 - Non-Reversing Starters with Electronic Overloads
SQUARE DNon-Reversing Starters with Electronic Overloads

SQUARE D NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 4

The SQUARE D NEMA Magnetic Motor Starter is a non-reversing starter with an electronic overload, designed for three-phase applications. This NEMA Size 4 unit features a 135 A rating, a 480V AC coil voltage, and screw…

SKU 3G-OTH-43417

Brand
SQUARE D
Item
NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 4
Category
Non-Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SQUARE D
Manufacturer Part Number
8536SFO1V06H30
Type
NEMA Size 4, 135 A
Phase
Three
Poles
3
AC Coil
480V
Operator
None
Coil Voltage
480V AC
Operator Controls
None
Includes Pilot Light
No
Thermal Units Required
None (Not Applicable to Electronic Overloads)
Terminal Connection Type
Screw Clamp Terminals
Auxiliary Contacts Included
No Auxiliary Contacts Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SQUARE D Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SQUARE D NEMA Magnetic Motor Starter is a non-reversing starter with an electronic overload, designed for three-phase applications. This NEMA Size 4 unit features a 135 A rating, a 480V AC coil voltage, and screw clamp terminals. It includes no auxiliary contacts, pilot light, or operator controls, and requires no thermal units as it uses an electronic overload.

Frequently Asked Questions

What is the SQUARE D NEMA Magnetic Motor Starter used for?

The SQUARE D NEMA Magnetic Motor Starter is used to start and stop three-phase motors in industrial applications. Its electronic overload protects motors from damage due to overcurrent. Common uses include conveyors, pumps, and compressors in manufacturing and processing facilities.

What are the specifications of the SQUARE D 8536SFO1V06H30 motor starter?

This SQUARE D starter is a non-reversing, NEMA Size 4 unit rated at 135 A with 3 poles and a 480V AC coil. It uses screw clamp terminals and an electronic overload (no thermal units needed). It has no auxiliary contacts, pilot light, or operator controls.

Where to buy the SQUARE D 8536SFO1V06H30 motor starter worldwide?

You can source the SQUARE D 8536SFO1V06H30 motor starter through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to select the correct NEMA size for a SQUARE D motor starter?

Select the NEMA size based on the motor's full-load current and voltage. For a 135 A rating, NEMA Size 4 is appropriate. Ensure the coil voltage matches your control circuit (e.g., 480V AC). The SQUARE D electronic overload eliminates the need for separate thermal units.
