SQUARE D NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1 - Non-Reversing Starters with Electronic Overloads
SQUARE DNon-Reversing Starters with Electronic Overloads

SQUARE D NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1

The SQUARE D NEMA Magnetic Motor Starter is a non-reversing starter with an electronic overload, designed for three-phase applications. This NEMA Size 1 unit features a 208V AC coil, 27 A rating, and screw clamp…

SKU 3G-OTH-42286

Brand
SQUARE D
Item
NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1
Category
Non-Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SQUARE D
Manufacturer Part Number
8536SCO3V08H30
Type
NEMA Size 1, 27 A
Phase
Three
Poles
3
AC Coil
208V
Operator
None
Coil Voltage
208V AC
Operator Controls
None
Includes Pilot Light
No
Thermal Units Required
None (Not Applicable to Electronic Overloads)
Terminal Connection Type
Screw Clamp Terminals
Auxiliary Contacts Included
No Auxiliary Contacts Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SQUARE D Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SQUARE D NEMA Magnetic Motor Starter is a non-reversing starter with an electronic overload, designed for three-phase applications. This NEMA Size 1 unit features a 208V AC coil, 27 A rating, and screw clamp terminals, with no operator controls, pilot light, or auxiliary contacts included.

Frequently Asked Questions

What is the SQUARE D 8536SCO3V08H30 magnetic motor starter used for?

The SQUARE D NEMA Magnetic Motor Starter is used to start and stop three-phase motors in industrial applications such as conveyors, pumps, and compressors. Its non-reversing design and electronic overload protect motors from damage, making it suitable for continuous-duty equipment across manufacturing and processing facilities.

What are the specifications of the SQUARE D 8536SCO3V08H30?

This SQUARE D starter is NEMA Size 1, rated 27 A, with 3 poles and a 208V AC coil. It uses screw clamp terminals and includes an electronic overload (no thermal units required). It has no operator controls, pilot light, or auxiliary contacts. The part number is 8536SCO3V08H30.

Where to buy the SQUARE D 8536SCO3V08H30 worldwide?

3G Electric supplies the SQUARE D 8536SCO3V08H30 magnetic motor starter to customers worldwide. As a global industrial solutions provider, we handle full logistics and customs clearance to deliver this NEMA Size 1 starter to your facility. Contact us for availability and lead time.

How to select the correct NEMA size for a SQUARE D motor starter?

Select NEMA size based on motor full-load current and voltage. For a SQUARE D Size 1 starter like the 8536SCO3V08H30, it handles up to 27 A at 208V AC. Match the coil voltage to your control circuit (208V AC here) and ensure the starter's pole count matches your three-phase motor.
