SQUARE D NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 2 - Non-Reversing Starters with Electronic Overloads
SQUARE DNon-Reversing Starters with Electronic Overloads

SQUARE D NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 2

The SQUARE D NEMA Magnetic Motor Starter is a non-reversing starter with an electronic overload, designed for three-phase applications. This NEMA Size 2 unit is rated for 45 A and features a 220/240V AC coil, screw…

SKU 3G-OTH-43776

Brand
SQUARE D
Item
NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 2
Category
Non-Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SQUARE D
Manufacturer Part Number
8536SDO1V03H30
Type
NEMA Size 2, 45 A
Phase
Three
Poles
3
AC Coil
240V
Operator
None
Coil Voltage
220/240V AC
Operator Controls
None
Includes Pilot Light
No
Thermal Units Required
None (Not Applicable to Electronic Overloads)
Terminal Connection Type
Screw Clamp Terminals
Auxiliary Contacts Included
No Auxiliary Contacts Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SQUARE D Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SQUARE D NEMA Magnetic Motor Starter is a non-reversing starter with an electronic overload, designed for three-phase applications. This NEMA Size 2 unit is rated for 45 A and features a 220/240V AC coil, screw clamp terminals, and no auxiliary contacts or operator controls.

Frequently Asked Questions

What is the SQUARE D 8536SDO1V03H30 magnetic motor starter used for?

The SQUARE D 8536SDO1V03H30 is a NEMA Size 2 non-reversing magnetic motor starter used to start and stop three-phase motors in industrial applications such as pumps, conveyors, and compressors. It features an electronic overload relay for motor protection and a 240V AC coil.

What are the specifications of the SQUARE D 8536SDO1V03H30?

This SQUARE D starter is NEMA Size 2, rated 45 A, with 3 poles and a 220/240V AC coil. It has screw clamp terminals, no auxiliary contacts, no operator controls, and no pilot light. The electronic overload eliminates the need for thermal units. MPN: 8536SDO1V03H30.

Where to buy the SQUARE D 8536SDO1V03H30 worldwide?

3G Electric supplies the SQUARE D 8536SDO1V03H30 magnetic motor starter worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your site. Contact us for availability and lead time.

How to select the correct overload for the SQUARE D 8536SDO1V03H30?

The SQUARE D 8536SDO1V03H30 includes an electronic overload relay, so no separate thermal units are required. To select the correct starter size, match the motor full-load current (FLA) to the starter amp rating—45 A for this NEMA Size 2 unit. Always verify coil voltage matches your control circuit.
