SQUARE D NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1 - Non-Reversing Starters with Electronic Overloads
SQUARE DNon-Reversing Starters with Electronic Overloads

SQUARE D NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1

The SQUARE D NEMA Magnetic Motor Starter is a non-reversing starter with an electronic overload, designed for three-phase applications. This NEMA Size 1 unit is rated for 27 A and features a 220/240V AC coil, screw…

SKU 3G-OTH-42342

Brand
SQUARE D
Item
NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1
Category
Non-Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SQUARE D
Manufacturer Part Number
8536SCO3V03H30
Type
NEMA Size 1, 27 A
Phase
Three
Poles
3
AC Coil
240V
Operator
None
Coil Voltage
220/240V AC
Operator Controls
None
Includes Pilot Light
No
Thermal Units Required
None (Not Applicable to Electronic Overloads)
Terminal Connection Type
Screw Clamp Terminals
Auxiliary Contacts Included
No Auxiliary Contacts Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SQUARE D Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SQUARE D NEMA Magnetic Motor Starter is a non-reversing starter with an electronic overload, designed for three-phase applications. This NEMA Size 1 unit is rated for 27 A and features a 220/240V AC coil, screw clamp terminals, and no auxiliary contacts or operator controls.

Frequently Asked Questions

What is the SQUARE D 8536SCO3V03H30 magnetic motor starter used for?

The SQUARE D NEMA Size 1 magnetic motor starter is used to start and stop three-phase motors in industrial applications such as conveyors, pumps, and compressors. Its electronic overload protects the motor from damage due to overcurrent, making it suitable for continuous-duty machinery.

What are the specifications of the SQUARE D 8536SCO3V03H30?

This non-reversing starter has 3 poles, NEMA Size 1, rated 27 A with a 220/240V AC coil. It uses screw clamp terminals, includes no auxiliary contacts or pilot light, and features an electronic overload (no thermal units required). It is a SQUARE D product, part number 8536SCO3V03H30.

Where to buy the SQUARE D 8536SCO3V03H30 worldwide?

3G Electric supplies the SQUARE D 8536SCO3V03H30 magnetic motor starter to customers worldwide. As a global industrial solutions provider, we handle full logistics, customs clearance, and delivery to your facility. Contact us for pricing and lead time on this NEMA Size 1 starter.

How to select the correct overload for a SQUARE D NEMA Size 1 starter?

For the SQUARE D 8536SCO3V03H30 with an electronic overload, no separate thermal units are needed. Set the overload trip current according to the motor's full-load amperage rating, typically between 27 A and the motor nameplate value. Always follow the manufacturer's wiring diagram and local electrical codes.
