SQUARE D NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1 - Non-Reversing Starters with Electronic Overloads
SQUARE DNon-Reversing Starters with Electronic Overloads

SQUARE D NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1

The SQUARE D NEMA Magnetic Motor Starter is a non-reversing starter with an electronic overload, designed for three-phase applications. This NEMA Size 1 unit is rated for 27 A and features a 110/120V AC coil, with…

SKU 3G-OTH-42016

Brand
SQUARE D
Item
NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1
Category
Non-Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SQUARE D
Manufacturer Part Number
8536SCO3V02H30S
Type
NEMA Size 1, 27 A
Phase
Three
Poles
3
AC Coil
120V
Operator
None
Coil Voltage
110/120V AC
Operator Controls
None
Includes Pilot Light
No
Thermal Units Required
None (Not Applicable to Electronic Overloads)
Terminal Connection Type
Screw Clamp Terminals
Auxiliary Contacts Included
No Auxiliary Contacts Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SQUARE D Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SQUARE D NEMA Magnetic Motor Starter is a non-reversing starter with an electronic overload, designed for three-phase applications. This NEMA Size 1 unit is rated for 27 A and features a 110/120V AC coil, with screw clamp terminals for secure wiring. It includes no operator controls, pilot light, or auxiliary contacts, and thermal units are not applicable due to the electronic overload design.

Frequently Asked Questions

What is the SQUARE D NEMA Magnetic Motor Starter used for?

The SQUARE D NEMA Magnetic Motor Starter is used to start and stop three-phase motors in industrial applications. It provides overload protection via its electronic overload relay, making it suitable for pumps, conveyors, fans, and compressors in manufacturing and processing plants.

What are the specifications of the SQUARE D 8536SCO3V02H30S motor starter?

This SQUARE D starter is a non-reversing, NEMA Size 1 unit rated for 27 A with three poles. It has a 110/120V AC coil, screw clamp terminals, and an electronic overload. No operator controls, pilot light, or auxiliary contacts are included. Thermal units are not applicable.

Where to buy the SQUARE D NEMA Size 1 motor starter worldwide?

You can source the SQUARE D 8536SCO3V02H30S motor starter through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time.

How to install a SQUARE D NEMA magnetic motor starter?

Mount the starter on a flat surface, connect three-phase power to the line terminals, and wire the motor to the load terminals. Connect the 120V AC coil to the control circuit. Set the electronic overload relay to the motor's full-load current. Always follow local electrical codes and lockout/tagout procedures.

Used in

Common applications for SQUARE D
Commercial building electrical panels — Square D QO series plug-in circuit breakers for branch circuit protection
Industrial motor control centers — Square D QOB series bolt-on breakers in NQOD panelboards
Heating equipment installations — Square D QOU series unit-mount breakers for overcurrent protection
Outdoor electrical distribution — Square D L-Frame enclosures housing LAL/LHL breakers for 400 A service
Indoor facility power distribution — Square D Q-Frame enclosures with QBL/QDL breakers for 225 A circuits
Retrofit and replacement in existing Square D load centers — QO series breakers for 120/240V AC systems
