SQUARE D NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 4 - Non-Reversing Starters with Electronic Overloads
SQUARE DNon-Reversing Starters with Electronic Overloads

SQUARE D NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 4

The SQUARE D NEMA Magnetic Motor Starter is a non-reversing starter with electronic overloads, model 8536SFO1V02H30S. It is a three-phase, NEMA Size 4 unit rated at 135 A with a 110/120V AC coil voltage. This starter…

SKU 3G-OTH-43263

Brand
SQUARE D
Item
NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 4
Category
Non-Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SQUARE D
Manufacturer Part Number
8536SFO1V02H30S
Type
NEMA Size 4, 135 A
Phase
Three
Poles
3
AC Coil
120V
Operator
None
Coil Voltage
110/120V AC
Operator Controls
None
Includes Pilot Light
No
Thermal Units Required
None (Not Applicable to Electronic Overloads)
Terminal Connection Type
Screw Clamp Terminals
Auxiliary Contacts Included
No Auxiliary Contacts Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SQUARE D Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SQUARE D NEMA Magnetic Motor Starter is a non-reversing starter with electronic overloads, model 8536SFO1V02H30S. It is a three-phase, NEMA Size 4 unit rated at 135 A with a 110/120V AC coil voltage. This starter features screw clamp terminals and includes no auxiliary contacts, pilot light, or operator controls.

Frequently Asked Questions

What is the SQUARE D 8536SFO1V02H30S magnetic motor starter used for?

The SQUARE D 8536SFO1V02H30S is a NEMA Size 4 non-reversing magnetic motor starter used to start and protect three-phase motors in industrial applications such as pumps, conveyors, and compressors. It features an electronic overload relay and a 120V AC coil, providing reliable motor control in manufacturing and process industries.

What are the specifications of the SQUARE D 8536SFO1V02H30S starter?

The SQUARE D 8536SFO1V02H30S is a three-phase, NEMA Size 4 non-reversing starter rated at 135 A with a 110/120V AC coil voltage. It has 3 poles, screw clamp terminals, and includes electronic overloads. No auxiliary contacts, pilot light, or operator controls are included. Thermal units are not required for electronic overloads.

Where to buy the SQUARE D 8536SFO1V02H30S starter worldwide?

3G Electric supplies the SQUARE D 8536SFO1V02H30S magnetic motor starter worldwide. As a global industrial equipment distributor since 1990, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time; we source and deliver this SQUARE D starter to any country.

How to install the SQUARE D 8536SFO1V02H30S magnetic motor starter?

Install the SQUARE D 8536SFO1V02H30S by mounting it on a flat surface, connecting three-phase power to the line terminals, and the motor to the load terminals. Wire the 120V AC coil to a control circuit. Set the electronic overload relay per motor full-load amps. Always follow local electrical codes and disconnect power before installation.
