SQUARE D NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 4 - Non-Reversing Starters with Electronic Overloads
SQUARE DNon-Reversing Starters with Electronic Overloads

SQUARE D NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 4

The SQUARE D NEMA Magnetic Motor Starter is a non-reversing starter with an electronic overload, designed for three-phase applications. This NEMA Size 4 unit features a 135 A rating and a 220/240V AC coil, with screw…

SKU 3G-OTH-43376

Brand
SQUARE D
Item
NEMA Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 4
Category
Non-Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

SQUARE D
Manufacturer Part Number
8536SFO1V03H30
Type
NEMA Size 4, 135 A
Phase
Three
Poles
3
AC Coil
240V
Operator
None
Coil Voltage
220/240V AC
Operator Controls
None
Includes Pilot Light
No
Thermal Units Required
None (Not Applicable to Electronic Overloads)
Terminal Connection Type
Screw Clamp Terminals
Auxiliary Contacts Included
No Auxiliary Contacts Included
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

SQUARE D Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The SQUARE D NEMA Magnetic Motor Starter is a non-reversing starter with an electronic overload, designed for three-phase applications. This NEMA Size 4 unit features a 135 A rating and a 220/240V AC coil, with screw clamp terminals and no auxiliary contacts or operator controls included.

Frequently Asked Questions

What is the SQUARE D 8536SFO1V03H30 magnetic motor starter used for?

The SQUARE D 8536SFO1V03H30 is a NEMA Size 4 non-reversing magnetic motor starter used to control three-phase motors in industrial applications such as pumps, conveyors, and compressors. It provides reliable starting and stopping with electronic overload protection, suitable for demanding environments requiring a 135 A rating and 240V AC coil.

What are the specifications of the SQUARE D 8536SFO1V03H30?

The SQUARE D 8536SFO1V03H30 is a NEMA Size 4, 3-pole, non-reversing magnetic motor starter rated at 135 A with a 220/240V AC coil. It features screw clamp terminals, electronic overload protection, and no auxiliary contacts or operator controls. The phase is three-phase, and thermal units are not applicable.

Where to buy the SQUARE D 8536SFO1V03H30 worldwide?

You can source the SQUARE D 8536SFO1V03H30 from 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time; we supply genuine SQUARE D components for industrial motor control applications.

How to select the correct overload for the SQUARE D 8536SFO1V03H30?

The SQUARE D 8536SFO1V03H30 includes an electronic overload, so no separate thermal units are required. To select the correct setting, match the motor full-load current (FLC) to the overload adjustment range. Consult the motor nameplate and SQUARE D documentation for proper setup. 3G Electric can provide sourcing support for this starter.
