EATON Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1, 27 A - Non-Reversing Starters with Electronic Overloads
EATONNon-Reversing Starters with Electronic Overloads

EATON Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1, 27 A

The EATON NEMA Magnetic Motor Starter is a non-reversing starter with electronic overloads, three poles, NEMA Size 1, and a 27 A rating. It features a 440/480V AC coil voltage, a 1NO auxiliary contact form, and a…

SKU 3G-OTH-42404

Brand
EATON
Item
Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1, 27 A
Category
Non-Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
AN19DN0C5E020
Type
NEMA Size 1, 27 A
Phase
Three
Poles
3
AC Coil
480V
Operator
None
Coil Voltage
440/480V AC
Operator Controls
None
Signaling Features
Pilot Light
Auxiliary Contact Form
1NO
Thermal Units Required
None (Not Applicable to Electronic Overloads)
Auxiliary Contacts Included
1NO
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON NEMA Magnetic Motor Starter is a non-reversing starter with electronic overloads, three poles, NEMA Size 1, and a 27 A rating. It features a 440/480V AC coil voltage, a 1NO auxiliary contact form, and a pilot light signaling feature. This three-phase starter includes one normally open auxiliary contact and requires no thermal units.

Frequently Asked Questions

What is the EATON NEMA Magnetic Motor Starter used for?

The EATON NEMA Magnetic Motor Starter is used to start and stop three-phase AC motors in industrial applications such as pumps, fans, and conveyors. It provides overload protection via its electronic overload relay and is suitable for environments requiring NEMA Size 1 ratings up to 27 A.

What are the specifications of the EATON AN19DN0C5E020 motor starter?

The EATON AN19DN0C5E020 is a non-reversing, three-pole NEMA Size 1 starter rated at 27 A with a 440/480V AC coil. It includes one normally open auxiliary contact and a pilot light. The electronic overload requires no thermal units. It is designed for three-phase systems.

Where to buy the EATON AN19DN0C5E020 motor starter worldwide?

You can source the EATON AN19DN0C5E020 motor starter through 3G Electric, a global industrial equipment distributor. We handle full logistics, customs clearance, and delivery to worldwide destinations. Contact us for availability and lead time on this EATON-branded NEMA Size 1 starter.

How to select the correct NEMA size for an EATON motor starter?

Select the NEMA size based on the motor's full-load current and voltage. For the EATON AN19DN0C5E020, NEMA Size 1 covers up to 27 A at 480V AC. Match the coil voltage (440/480V AC) to your control circuit. Always verify the starter's pole count and auxiliary contact configuration for your application.
