EATON Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1, 27 A - Non-Reversing Starters with Electronic Overloads
EATONNon-Reversing Starters with Electronic Overloads

EATON Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1, 27 A

The EATON NEMA Magnetic Motor Starter is a non-reversing starter with electronic overloads, three poles, NEMA Size 1, and a 27 A rating. It features a 440/480V AC coil voltage, a 1NO auxiliary contact, and a pilot…

SKU 3G-OTH-42532

Brand
EATON
Item
Magnetic Motor Starter: Non-Reversing, 3 Poles, NEMA Size 1, 27 A
Category
Non-Reversing Starters with Electronic Overloads
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

EATON
Manufacturer Part Number
AN19DN0C5E045
Type
NEMA Size 1, 27 A
Phase
Three
Poles
3
AC Coil
480V
Operator
None
Coil Voltage
440/480V AC
Operator Controls
None
Signaling Features
Pilot Light
Auxiliary Contact Form
1NO
Thermal Units Required
None (Not Applicable to Electronic Overloads)
Auxiliary Contacts Included
1NO
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

EATON Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The EATON NEMA Magnetic Motor Starter is a non-reversing starter with electronic overloads, three poles, NEMA Size 1, and a 27 A rating. It features a 440/480V AC coil voltage, a 1NO auxiliary contact, and a pilot light signaling feature. This three-phase starter is designed for industrial motor control applications.

Frequently Asked Questions

What is the EATON NEMA Magnetic Motor Starter used for?

The EATON NEMA Magnetic Motor Starter is used for starting and stopping three-phase industrial motors. It provides overload protection via its electronic overloads and is suitable for applications requiring non-reversing motor control, such as conveyors, pumps, and fans.

What are the specifications of the EATON AN19DN0C5E045 motor starter?

This EATON starter is a NEMA Size 1, non-reversing, three-pole unit rated at 27 A. It has a 440/480V AC coil voltage, includes one normally open auxiliary contact, and features a pilot light for signaling. It uses electronic overloads and requires no thermal units.

Where to buy the EATON AN19DN0C5E045 motor starter worldwide?

3G Electric supplies the EATON AN19DN0C5E045 motor starter worldwide. As a global industrial equipment distributor, we handle full logistics, customs clearance, and delivery to your location. Contact us for availability and lead time.

How to select the correct overload protection for this EATON starter?

This EATON starter features electronic overloads, so no separate thermal units are needed. To select the correct setting, match the motor full-load current to the overload adjustment range specified in the starter's manual. Always consult the manufacturer's documentation for proper configuration.
