Beckett CF2300 Oil Burner 17.00 to 19.90 GPH | AC Power
Heavy-duty oil burner designed for commercial heating, steam generation, and pressure washing applications. Delivers 17–19.9 GPH with advanced combustion technology and flexible voltage options.
SKU 3G-BKT-00064
Also listed as: BCF 304 · BCF-304
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineerNo account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h
Not sure this is the right part? Get a recommendation.
Need installation or engineering help?
Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineerAsk a question
Beckett Products
3G Electric (S) Pte. Ltd. — Singapore
Product Description
Heavy-duty oil burner designed for commercial heating, steam generation, and pressure washing applications. Delivers 17–19.9 GPH with advanced combustion technology and flexible voltage options.
Key Features
- Fuel delivery range: 17.00–19.90 GPH
- Direct spark ignition system
- Linkageless air damper adjustment
- Single nozzle operation at 125–150 PSI (low) and 250–300 PSI (high)
- Cast aluminum housing for durability and reduced noise
- 3/4 HP motor with standard 110V/60Hz
- Optional 240V single-phase or 208/240/480V three-phase
- UL/cUL certified
- Biodiesel B6–B20 compatible (D396 certified)
- Power On and Fuel On indicator lights
- Junction box with terminal strip for simplified wiring
- Suitable for commercial heating, steam, and pressure washing
Used in
Common applications for BeckettAmerican-spec food-processing boiler burners — AFG scheduled-maintenance parts
Institutional kitchen and cafeteria plant — SF series for 3–7 GPH continuous duty
Commercial gas / dual-fuel — CG10 / CG15 / CG25 for medium-scale installations
Marine and offshore auxiliary plant — Beckett semi-commercial oil burners
Retrofit swap from ageing Italian burners where customer prefers American-style simpler service catalog
