CRYDOM Solid State Relay: Surface Mounted - Surface-Mounted Relays
CRYDOMSurface-Mounted Relays

CRYDOM Solid State Relay: Surface Mounted

The CRYDOM D53TP50CH is a panel-mounted solid-state relay with a surface-mounted design, offering a Form A (SPST-NO) switch configuration. It provides an AC output with a voltage range of 48 to 530V AC and requires a…

SKU 3G-OTH-38132

Brand
CRYDOM
Item
Solid State Relay: Surface Mounted
Category
Surface-Mounted Relays
Available to Order
Trade pricing by quote — replies within 24h
Qty
WhatsApp an engineer
No account needed — your quote request goes straight to our engineers. A free account lets you track quotes and re-order faster.
Worldwide Shipping
Air & sea freight
Datasheet on Request
Technical specs
1-Day Quote
Replies within 24h

Technical Specifications

CRYDOM
Brand
CRYDOM
Finger Safe
Yes
Current Type
DC
Input Current
35 mA
Mounting Style
Panel
Output Voltage
48 to 530V AC
Switch Configuration
Form A
Voltage/Current Type
AC Output
Electrical Connection
Saddle Clamp
Manufacturer Part Number
D53TP50CH
Maximum Output Current without Heat Sink
Not Recommended
View Full Spec Sheet

Technical Documents

No technical documents available for this product.
Request documentation →
Not sure this is the right part? Get a recommendation.

Need installation or engineering help?

Installation, commissioning, maintenance plans, system design, and bundled product + service quotes — one team handles the full scope.
Talk to an engineer

Ask a question

CRYDOM Products
3G Electric (S) Pte. Ltd. — Singapore

Product Description

The CRYDOM D53TP50CH is a panel-mounted solid-state relay with a surface-mounted design, offering a Form A (SPST-NO) switch configuration. It provides an AC output with a voltage range of 48 to 530V AC and requires a DC input current of 35 mA. The relay features finger-safe saddle-clamp electrical connections and is not recommended for use without a heat sink at its 50 A maximum output current.
