Omron 3G-OTH-40296 — Technical Specifications

Name: Omron 3G-OTH-40296 OMRON Solid State Relay: Surface Mounted, 50 A Max Output Current, Photocoupler, AC Output (MPN G3NA-650B-AC100-240). Key specifications — Brand: OMRON; Current Type: AC; Electrical Connection: Screw Clamp; Finger Safe: Yes; Input Current: 17.4 to 35 A; Maximum Output Current without Heat Sink: 6 A; Mounting Style: Surface; Output Voltage: 400 to 600V AC.
Brand: Omron

The OMRON Solid State Relay is a surface-mounted AC output relay with a Form A switch configuration. It features a screw clamp electrical connection, is finger safe, and accepts an input current of 17.4 to 35 A. The relay provides an output voltage of 400 to 600V AC, with a maximum output current without heat sink of 6 A.

View Product & Quote

Technical Specifications

Parameter	Value
Brand	OMRON
Finger Safe	Yes
Current Type	AC
Input Current	17.4 to 35 A
Mounting Style	Surface
Output Voltage	400 to 600V AC
Switch Configuration	Form A
Voltage/Current Type	AC Output
Electrical Connection	Screw Clamp
Manufacturer Part Number	G3NA-650B-AC100-240
Maximum Output Current Without Heat Sink	6 A
